Stainless Steel Welded Wire Mesh is a durable and corrosion-resistant mesh product made by welding high-quality stainless steel wires into uniform square or rectangular grids. Known for its strength, rigidity, and resistance to rust, chemicals, and harsh environments, it is ideal for both indoor and outdoor use without requiring additional coatings. Commonly manufactured from stainless steel grades 304, 304L, 316, and 316L, this mesh is widely used in fencing, construction reinforcement, machinery guards, food processing, animal enclosures, and architectural applications.

Material Grades

Mesh Opening Sizes

Stainless Steel Welded Wire Mesh is available in a wide range of aperture configurations to suit various applications:

Mesh Opening		Wire Diameter <BWG>	Rolls Size
In inch	In metric unit (mm)
1/4″ x 1/4″	6.4mm x 6.4mm	22,23,24	1mx30m, 3’x100′, 4’x100′,5’x100′, 6’x100′
3/8″ x 3/8″	10.6mm x 10.6mm	19,20,21,22
1/2″ x 1/2″	12.7mm x 12.7mm	16,17,18,19,20,21,22,23
5/8″ x 5/8″	16mm x 16mm	18,19,20,21,
3/4″ x 3/4″	19.1mm x 19.1mm	16,17,18,19,20,21
1″ x 1/2″	25.4mm x 12.7mm	16,17,18,19,20,21
1-1/2″ x 1-1/2″	38mm x 38mm	14,15,16,17,18,19
1″ x 2″	25.4mm x 50.8mm	14,15,16
2″ x 2″	50.8mm x 50.8mm	12,13,14,15,16

Uniform wire diameter across both warp and weft ensures a flat, strong structure with no deformation.

• Roll Widths and Panel Dimensions
• Stainless Steel Welded Wire Mesh is available in both rolls and panels:
• Roll Widths: 24″, 36″, 48″, 60″, and 72″ (609.6 mm to 1828.8 mm)
• Roll Lengths: 50 ft, 100 ft, and 150 ft (15.24 m to 45.72 m)
• Panel Sizes: Standard panels include 2.0 m × 3.0 m, with custom sizes manufactured upon request

All products are securely packaged in moisture-resistant materials to ensure clean and damage-free delivery.
Its adaptability, hygiene standards, and resilience to harsh elements make it suitable for indoor, outdoor, and sanitary environments.

Customization Options

Huacheng provides full customization for Stainless Steel Welded Wire Mesh:

• Custom roll widths, lengths, mesh apertures, and wire gauges
• OEM service with private label packaging
• Cut-to-size panels based on construction or fencing drawings
• Fast production lead time for both bulk and small quantity orders
